350L Tank Gravity Fed Safety shower

1500L Tank Gravity Fed Safety shower

EMAIL


It is a good choice when there is no constant supply of water being guaranteed. Equally, if there is insufficient water pressure or inadequate flow rates a tank fed safety shower & eyewash is essential. This 1500 litre capacity model meets EN15154 and ANSI Z358.1-2014 requirements, providing 76 litres of potable water per minute for the recommended 15 minutes.

For outdoor use in hot climates, extra chiller unit is required to prevent water within the tank reaching dangerous levels and potentially scalding a casualty upon activation. Choose from a selection of chiller options to guarantee the provision of tepid water. The range includes units suited to both hazardous and non-hazardous environments.

For indoor use, this model assists in maintaining a steady water temperature within the tank.



Model WDJ8804-6
Size 1200*1200*3950mm
Material Stainless steel 304 / SS316L
Certificate & Standard  ANSI Z 358.1-2014, EN15154.1/2:2006
Wall Thickness  1.2mm
Pipe thickness  2.5-3mm
Function  eye washing, body showering
Working pressure  0.2MPa-0.6MPa
Test pressure  1.0MPa
Working environment temperature  5 ° C -35 ° C
Inlet size  NPT 1 1/4″
Drain size  NPT 2″
Eyewash flow rate  ≥11.4L/min
Shower flow rate  ≥75.7L/min
CustomizableColor, external dimensions, shower basin, wash basin, ABS material, Pipe size, sound and light alarm, remote wireless alarm system
Water tank 350L
FlowGravity feed
MountingSelf standing
